SPECIFICATIONS
-
Voltage rating: 250V AC
-
Current rating: 3A AC, DC
-
Withstand voltage: AC 1,000 V/min
-
Insulation resistance: 1,000M Ω min
-
Temperature range: -25°C ~ +85°C
-
Contact resistance:
Initial value / 10m Ω max
After environmental testing / 20m Ω max -
Applicable P.C.B. thickness: 0.8 ~ 1.6mm
