Specification
-
Current Rating: 3Amp
-
Insulation Resistance: 5000M Ω Min.
-
Dielectric Withstanding: 600V AC
-
Contact Resistance: 20mΩ Max.
-
Operating Temperature: -40°C to +105°C
Materials (UL 94V-0)
-
Contact Material: Brass
-
Contact Plating: Gold/Tin over Nickel
-
Insulation Material: Glass Filled Polyester
| Pin | PARD NO. | Pin | PARD NO. | Pin | PARD NO. | Pin | PARD NO. |
|---|---|---|---|---|---|---|---|
| 6 | 8002S-6 | 39 | 8002S-39 | 72 | 8002S-72 | 105 | 8002S-105 |
| 9 | 8002S-9 | 42 | 8002S-42 | 75 | 8002S-75 | 108 | 8002S-108 |
| 12 | 8002S-12 | 45 | 8002S-45 | 78 | 8002S-78 | 111 | 8002S-111 |
| 15 | 8002S-15 | 48 | 8002S-48 | 81 | 8002S-81 | 114 | 8002S-114 |
| 18 | 8002S-18 | 51 | 8002S-51 | 84 | 8002S-84 | 117 | 8002S-117 |
| 21 | 8002S-21 | 54 | 8002S-54 | 87 | 8002S-87 | 120 | 8002S-120 |
| 24 | 8002S-24 | 57 | 8002S-57 | 90 | 8002S-90 | 123 | 8002S-123 |
| 27 | 8002S-27 | 60 | 8002S-60 | 93 | 8002S-93 | 126 | 8002S-126 |
| 30 | 8002S-30 | 63 | 8002S-63 | 96 | 8002S-96 | 129 | 8002S-129 |
| 33 | 8002S-33 | 66 | 8002S-66 | 99 | 8002S-99 | 132 | 8002S-132 |
| 36 | 8002S-36 | 69 | 8002S-69 | 102 | 8002S-102 |
