Specification
-
Current Rating: 3Amp
-
Insulation: 5000M Ω Min.
-
Dielectric Withstanding: 600V AC
-
Contact Resistance: 20m Ω Max.
-
Operating Temperature: -40°C to +105°C
Materials (UL 94V-0)
-
Contact Material: Brass
-
Contact Plating: Gold/Tin over Nickel
-
Insulation Material: Glass Filled Polyester
| Pin | PARD NO. | Pin | PARD NO. | Pin | PARD NO. | Pin | PARD NO. |
|---|---|---|---|---|---|---|---|
| 2 | 6012R-2 | 22 | 6012R-22 | 42 | 6012R-42 | 62 | 6012R-62 |
| 4 | 6012R-4 | 24 | 6012R-24 | 44 | 6012R-44 | 64 | 6012R-64 |
| 6 | 6012R-6 | 26 | 6012R-26 | 46 | 6012R-46 | 66 | 6012R-66 |
| 8 | 6012R-8 | 28 | 6012R-28 | 48 | 6012R-48 | 68 | 6012R-68 |
| 10 | 6012R-10 | 30 | 6012R-30 | 50 | 6012R-50 | 70 | 6012R-70 |
| 12 | 6012R-12 | 32 | 6012R-32 | 52 | 6012R-52 | 72 | 6012R-72 |
| 14 | 6012R-14 | 34 | 6012R-34 | 54 | 6012R-54 | 74 | 6012R-74 |
| 16 | 6012R-16 | 36 | 6012R-36 | 56 | 6012R-56 | 76 | 6012R-76 |
| 18 | 6012R-18 | 38 | 6012R-38 | 58 | 6012R-58 | 78 | 6012R-78 |
| 20 | 6012R-20 | 40 | 6012R-40 | 60 | 6012R-60 | 80 | 6012R-80 |
