Specification
-
Current Rating: 1Amp
-
Insulation Resistance: 5000MΩ Min.
-
Dielectric Withstanding: 600V AC
-
Contact Resistance: 20mΩ Max.
-
Operating Temperature: -40°C ~ +105°C
Materials (UL 94V-0)
-
Contact Material: Brass
-
Contact Plating: Gold/Tin over Nickel
-
Insulation Material: Glass Filled Polyester
| PIN | 90°C GOLD PLATING | PIN | 90°C GOLD PLATING |
|---|---|---|---|
| 4 | 5999R-4 | 24 | 5999R-24 |
| 6 | 5999R-6 | 26 | 5999R-26 |
| 8 | 5999R-8 | 28 | 5999R-28 |
| 10 | 5999R-10 | 30 | 5999R-30 |
| 12 | 5999R-12 | 32 | 5999R-32 |
| 14 | 5999R-14 | 34 | 5999R-34 |
| 16 | 5999R-16 | 36 | 5999R-36 |
| 18 | 5999R-18 | 38 | 5999R-38 |
| 20 | 5999R-20 | 40 | 5999R-40 |
| 22 | 5999R-22 | – | – |
