Specification
-
Current Rating: 1 Amp
-
Insulation Resistance: 5000MΩ Min.
-
Dielectric Withstanding: 600V AC
-
Contact Resistance: 20mΩ Max.
-
Operating Temperature: -40°C to +105°C
Materials (UL 94V-0)
-
Contact Material: Phosphor Bronze
-
Contact Plating: Gold/Tin over Nickel
-
Insulation Material: Glass Filled Polyester
| PIN | TIN PLATING | GOLD PLATING | PIN | TIN PLATING | GOLD PLATING |
|---|---|---|---|---|---|
| 2 | T-5997-R2 | G-5997-R2 | 22 | T-5997-R2 | G-5997-R2 |
| 4 | T-5997-R4 | G-5997-R4 | 24 | T-5997-R4 | G-5997-R4 |
| 6 | T-5997-R6 | G-5997-R6 | 26 | T-5997-R6 | G-5997-R6 |
| 8 | T-5997-R8 | G-5997-R8 | 28 | T-5997-R8 | G-5997-R8 |
| 10 | T-5997-R10 | G-5997-R10 | 30 | T-5997-R10 | G-5997-R10 |
| 12 | T-5997-R12 | G-5997-R12 | 32 | T-5997-R12 | G-5997-R12 |
| 14 | T-5997-R14 | G-5997-R14 | 34 | T-5997-R14 | G-5997-R14 |
| 16 | T-5997-R16 | G-5997-R16 | 36 | T-5997-R16 | G-5997-R16 |
| 18 | T-5997-R18 | G-5997-R18 | 38 | T-5997-R18 | G-5997-R18 |
| 20 | T-5997-R20 | G-5997-R20 | 40 | T-5997-R20 | G-5997-R20 |
