SPECIFICATIONS
-
Current Rating: 3A
-
Voltage Rating: 250V AC, DC
-
Insulation Resistance: 1,000M Ω min.
-
Withstand Voltage: 1,000V AC/minute
-
Temperature Range: -40°C ~ +105°C
-
Tolerance: ±0.2
2.54mm
■ CONNECTOR PART NO: 2540 / 2580
Material: Nylon 66, UL94V-2
Pitch: 2.54mm
■ CONTACT PIN
Material: Phos. Bronze C5159
Plating: Tin (Part No: 2540)
Gold (Part No: 2580)
Wire Range: AWG 22–28 Ribbon Cable or Electronic Cable.
Current Rating: 3A
Voltage Rating: 250V AC, DC
Insulation Resistance: 1,000M Ω min.
Withstand Voltage: 1,000V AC/minute
Temperature Range: -40°C ~ +105°C
Tolerance: ±0.2
